Performance characteristics
1. PLC programmable controller program automatic control;
2. Touchscreen LCD human-machine dialogue interface, humanized design; Third level administrator password access; 3. Computer remote communication function (optional);
4. UBS interface data export function (optional);
5. Automatic operation and manual operation modes; Display date and clock function; Temperature and humidity monitoring function; 6. Automatic leak detection function for cabin tightness (pressure drop method); Dual door electronic interlock function; 7. Voltage loss alarm function (sound and light signal); Cabin lighting: cold light source, illuminance ≥ 300lx; 8. Reserve detection ports for sharp particles, planktonic bacteria, and settling bacteria; Reserved cleaning interface (information provided by the buyer); 9. Reserve high-efficiency filter PAO detection port; Sterilizer catalytic decomposition function (optional for users); 10. Main data storage function;
Technical parameters
1. Working power supply: AC220 ± 22V 50Hz ± 1Hz
2. Merit?? Rate: 2500W
3. Dosage: 0-20ml/min
4. Air flow rate: 300L/min
5. Rong?? Volume: 0.2m3
6. Gasification temperature: 90℃
7. Noise: ≤ 68dB（A）
8. Sterilizer: 30% hydrogen peroxide solution
9. Killing rate: The killing rate of thermophilic fat spores and Bacillus subtilis var. niger reaches 6-log.
10. Sterilization cycle: ≤ 50min
11. Working mode: Continuous work
12. Heavy?? Quantity: Approximately 100kg
13. Dimensions: 825mm Х 710mm Х 1750mm
14. Internal cavity size: 600mmX600mmX560mm
15. Are you angry?? Flow: Vertical unidirectional flow
16. The wind?? Quantity: 500m3/h
17. High efficiency filter: H14 level
Application Fields
1. Used for the delivery of sterile raw materials;
2. Used for material transfer between sterile testing laboratories, microbiological testing laboratories, positive control laboratories, sampling rooms, material transfer rooms, and other rooms; 3. Used for material transfer in areas such as intensive care unit (ICU), negative pressure isolation ward/infectious disease ward, laboratory (virus, bacteria), operating room fever clinic, pathology and laboratory, drug dispensing room/intravenous drug dispensing center (PIVAS), supply room, ambulance, etc; 4. Used for the transfer of materials at different levels that cannot be sterilized at high temperatures (wet heat sterilization and dry heat sterilization).
